200l Ob Chav Chaw Nres Nkoj Qhib Irrigation Rotary Filling Line

Qhov no 200l ob qhov chaw nres tsheb qhib irrigation rotary filling kab yog tsim tshwj xeeb rau 100-300kg kua nruas ntim thiab ntse ntim system, nrog qhib qhov rais, tsis siv neeg nqa thiab zawv zawg qhov rooj yooj yim kaw;

Xa lus nug

Product Description

Txheej Txheem Flow:

Qhov no 200l ob qhov chaw nres tsheb qhib irrigation rotary filling kab yog tshwj xeeb tsim rau 100-300kg kua nruas ntim thiab ntse ntim system, nrog qhib qhov rais, tsis siv neeg nqa thiab zawv zawg qhov rooj yooj yim kaw; Tag nrho cov kab tuaj yeem tuaj yeem sau lub thoob, qhib thiab kaw qhov rooj, tuaj yeem txheeb xyuas lub qhov ncauj ntawm lub thoob, tuaj yeem kho lub qhov ncauj ntawm lub thoob, tuaj yeem qhib lub hau, tuaj yeem sau lub thoob, tuaj yeem ntsia hlau lub hau, ntsuas qhov xau thiab cia li tawm ntawm lub thoob.

Main Technical Parameters:

xplosion hom pov thawj:	Exd II BT4
Rated faib nqi:	50g (0.05Kg)
Sau ntau yam:	100.00 ~ 300.00 Kg
Chaw nres tsheb muaj nuj nqi:	npog qhib, filling, capping, leak detection
Siv tau nruas hom:	200L drum
Sau ceev:	txog 60-80 barrels / teev
Sau qhov tseeb:	± 0.1% F.S.
Khoom siv ntawm overcurrent element:	SUS 304
Main khoom siv:	stainless hlau
Gasket:	polytetrafluoroethylene
Hwj chim khoom siv:	AC380V / 50Hz, peb-theem tsib-xaim system; 4 kWm
Cua qhov chaw siab:	0.6 Mpa
